TC Componentes: tu distribuidor de diseño exclusivo para Bivar en España
TC Componentes: Impulsa tu diseño con tecnología optoelectrónica y asesoramiento especializado
Como distribuidor de diseño exclusivo de Bivar en España y Portugal, en TC Componentes ofrecemos un soporte único en la integración de soluciones optoelectrónicas.
Nos especializamos en guiar a nuestros clientes para aprovechar al máximo la tecnología avanzada de Bivar, desde los LEDs de alta calidad hasta las guías de luz flexibles y estancas.
Orientación técnica
individualizada para elegir el conector correcto.
Guías de luz flexibles
estancas y sin contaminación cruzada de colores.
Personalización
para aplicaciones en IoT, automoción y electrónica industrial.
En 2023, 32 millones de personas viajaron en alta velocidad controlada por radiobalizas con nuestros conectores
Catálogo de componentes Bivar
Light Pipes
Rigid Panel Press-Fit
Take a look at Bivar’s Panel Press-Fit. When you need a short-distance light pipe that presses securely into your panel, hovering as close as possible to SMD LED without touching, Bivar has you covered.
| RHD (216) | IP67 heavy-duty threaded retention for maximum protection in industrial-grade applications. - Available in 6mm or 9mm front-mount lens size. - Vertical and right-angle configurations. - Ideal for space-constrained spaces inside enclosures and on PCB’s. - Range of lengths and lens colors. - Use with panel thickness 0.059 in. (1.5mm) to 0.236 in. (6.0mm) - Hardware included. |
| PLTR (64) | IP67 threaded retention for maximum protection against dust and water. - Available in 3mm or 5mm front-mount lens size. - Lengths from .25 in. (6.4mm) to 3.0 in. (76.2mm). - Includes black or white polyurethane sealing gasket. - Use with panel thickness 0.047 in. to 0.093 in. - Hardware included. Torque 6-7 in-oz. |
| PLPC (81) | Countersink flush mount design for smooth panel appearance. - Available in 1mm, 2mm, 3mm front-mount lens sizes. - Standard Lengths: .100 in. (2.5mm) to .500 in. (12.7mm). - Metric Lengths: 3mm (.118”) to 10mm (.394”). - Use with panel thickness 0.047"- 0.093". - An ideal solution for application with overlays. - Crush-ribs for secure panel retention. |
| PLP1 (107) | Rear-mount 3mm lens size round shaped single station short distance light pipe. - 3mm lens size. Domed or flat lens appearance. - Lengths from .100 in. (2.5mm) to .750 in. (19.0mm). - Helps protect sensitive components from ESD. - Use with panel thickness .047 in. to .093 in. - Diffused, smoked, and color (blue, black, green, gray, red, yellow) lens options. |
| PLP2 (57) | Front-mount 3mm lens size round shaped single station short distance light pipe. - 3mm lens size. Domed lens appearance. - Lengths from .100 in. (2.5mm) to 1.20 in. (30.5mm). - Helps protect sensitive components from ESD. - Use with panel thickness .047 in. to .093 in. - Diffused, smoked, and color (blue, black, green, gray, red, yellow) lens options. |
| PLP5 (104) | Available in both front mount and rear mount, PLP5 is a 5mm lens size round shaped single station short distance light pipe. - Front-mount/Rear-mount 5mm lens size. Domed or flat lens appearance. - Lengths from .125 in. (3.2mm) to 1.50 in. (38.1 mm). - Helps protect sensitive components from ESD. - Use with panel thickness .047 in. to .093 in. - Diffused, smoked, and color (blue, black, green, gray, red, yellow) lens options. |
| PLW5 (49) | Wide-capture lower body provides micro-lens to capture and emit more LED light. - Available in 5mm front-mount low-profile lens size. - Lengths from .125 in. (3.2mm) to .5 in. (12.7mm). - Use with panel thickness 0.047"- 0.093". - Diffused, smoked, and color (blue, green, red, yellow) lens options. |
| MLPS-B (13640) | Light Pipe Positioning Tray Based on valuable customer insights, we've developed an innovative way to make light pipe installation even more efficient. The new MLPS-B Light Pipe Positioning Tray offers a streamlined approach that simplifies assembly and saves time. Positioning Tray is designed for precise alignment and enhanced support. Light pipe installation becomes more straightforward than ever. This approach improves retention, increases overall installation efficiency, or a more seamless assembly experience. |
| PLPQ (60) | Square shaped lens design provides a clean symmetrical alternative to round lens. - Available in 2mm, 3mm low-profile or flush front-mount lens size. - Lengths from .100 in. (2.5mm) to .500 in. (12.7mm). - Ideal for smaller display applications. - Use with panel thickness .047 in. to .093 in. - Clear and color (blue, black, green, gray, red, yellow) lens options. |
| SGLC (18) | IP68 Rated Sealing Gasket Lens Cap designed to provide ingress protection to LED status indication for applications exposed to harsh environments. - Available in 7.1mm lens diameter. - Fits into a .265 in. (6.7mm) round panel cutout - Available in low-profile dome and flat - Use with panel thickness .118 in. (2.56mm) and .250 in. (6.35mm) - Fresnel lens style with color (blue, green, red, yellow) lens options. |
Rigid Board Mount
Board Mount Rigid Light Pipes give you LED illumination exactly where you want it. Bivar offers a short-distance light pipe that can be mounted directly onto your PCB over an SMD LED.
| LPV (1079) | ZeroLightBleed™ surface mount adapter with built-in Bivar SMD LED and vertical light pipe. - Rear-mount 2mm, 3mm, 4mm lens size. Domed or flat lens appearance. - Lengths from .350 in. (8.9mm) to 2.00 in. (50.8mm). - Channels light directly to lens, eliminating light bleed at the source. - Available in single and multi-color SMD LED. - Polarity identification stripe on adapter for easy installation. |
| LPR (1726) | ZeroLightBleed™ surface mount adapter with built-in Bivar SMD LED and right-angle light pipe. - Rear-mount 3mm, 4mm, 5mm lens size. Domed or flat lens appearance. - Height options from .80 in. (20.3mm) to 1.25 in. (31.8mm). - Protrusion lengths from .70 in. (17.8mm) to 3.00 in. (76.2mm). - Channels light directly to lens, eliminating light bleed at the source. - Available in single and multi-color SMD LED. - Polarity identification stripe on adapter for easy installation. |
| VLP (33) | Rear-mount round or rectangular lens single station short distance light pipe. - 3mm round lens size. Domed or flat lens appearance. - Lengths from .200 in. (5.1mm) to .650 in. (16.5mm) - 4mm x 2mm rectangular lens. Length .500 in. (12.7mm) to 1.028 in. (26.1mm) - Designed for rugged applications that use Bivar SMD LEDs. - Diffused, and color (blue, black, green, gray, red, yellow) lens options. |
| SLP (51) | Rear-mount 90° variable centerline round lens single station short distance right angle light pipe. - 3mm round lens size. Domed or flat lens appearance. - Height from .200 in. (5.1mm) to .700 in. (17.8mm) - Protrusion length .100 in. (2.5mm) to .450 in. (11.4mm) - Provides excellent light transmission. Protects Bivar SMD LEDs from ESD. - Diffused, and color (blue, black, green, gray, red, yellow) lens options. |
| RLP (36) | Multi-station single-level right-angle light pipe array for use with Bivar SMD LEDs. - Rear-mount 3mm lens size. Flat lens appearance. - Height .197 in. (5.0mm) to .591 in. (15.0mm) - Protrusion Length .551in. (14.0mm) to .787 in. (20.0mm) - One to four station single-level configurations. - Use with Bivar single and multi-color SMD LED. |
| LP (3) | Two-level round lens single station short distance right angle light pipe. - 3mm round lens size. Low-profile lens appearance. - Height .360 in. (9.1mm) - Protrusion length .550 in. (14.0mm) - Provides excellent light transmission. Protects Bivar SMD LEDs from ESD. - Diffused, and color (blue, black, green, gray, red, yellow) lens options. |
| BGLP (1) | 10 uniform segment LED display using clear PMMA sheet material. - Body Length in.(mm): 1.47 in. (37.2mm) - Body Height in.(mm): 1.17 in. (29.6mm) - Body Width in.(mm): 0.24 in. (6.0mm) |
| PBLP (2) | Unique rear-mount push-button light pipe for use with various right angle switches. - 5.1mm round lens size. Low profile lens appearance. - Length 1.275 in. (32.4mm) - Helps protect sensitive components from ESD. - Diffused lens. |
Flexible Systems
When your design requires light to move longer distances, making its way around PCB obstacles, you need flexible light pipes from Bivar. Our flexible light pipes offer many mounting and built-in LED options to meet your luminosity requirements and adapters, with ESD protection for sensitive components. Need a customized approach? We can do that, too.
| UHF (55) | Clear silicone flexible light pipe with ZeroLightBleed™ adapter and patented pending rib design that seals and protects from ingress without a need for nut, washer, and gasket. - IP67 rated. - Available in 3mm, 4mm, and 5mm diameter. Length 0.250 in. to 6 in. - Wide temperature range of -40° to 200° Celsius. |
| SZSF (16) | Space Saving Small Footprint Flexible Light Pipe System Introducing Bivar’s SZSF Series: a small footprint flexible light pipe system built for today's compact, high-density PCB designs. With a 46% smaller adapter footprint and 30% height reduction – to answer the question “Do you have anything smaller?” SZSF enables precision adapter placement in electronic designs without compromising performance. Incorporating ZeroLightBleed™ technology with improved board mounting and light pipe adapter retention to ensure optimal light transmission and efficiency. Available in IP54 rated configurations for added protection. SZSF series provides easy one-piece sourcing and is ideal for design engineers seeking space-saving solutions. |
| SZR (31) | Right angle low profile ZeroLightBleed™ adapter system for Bivar SMD LED and Flexible Light Pipes. - Low profile for applications that need LED light routed in tight spaces. - Ideal for use in enclosures where height is limited and space constrained. - Range of IP54 lens sizes, shapes, and colors available. - Individual components paired to best optimize the Flexible Light Pipe system. - Available in 1mm, 2mm optical fiber diameter. Length 1.00 in. to over 100 ft. - Optical fiber colors: red, green, blue, yellow ,white, black. |
| SZ (3815) | ZeroLightBleed™ adapter system for Bivar SMD LED and flexible light pipe. IP54 option available. - 3 mounting options: Surface Mount, Firm Retention, Post Retention. - Adapter with built-in SMD LED option. Available in single and multi-color. - Reinforced packaging ideal for rugged environment applications. - 1mm, 2mm optical fiber diameter. Length 1.00 in. to over 100 ft. - Optical fiber colors: red, green, blue, yellow, white, black. - Range of lens sizes, shapes, and colors. |
| SMFLP (981) | Board mount adapter system for Bivar SMD LED and flexible light pipe. - Available in 1mm, 2mm optical fiber diameter. - Optical fiber length: 1.0 in. to over 100 ft. - Lens shapes: Round, Oval, Rectangular - Optical fiber colors: red, green, blue, yellow, white, black. - Range of lens sizes, and colors available. |
| Optical Fiber/Lens Cap (369) | Flexible optical fiber with attached lens for use with Bivar Flexible Light Pipe adapters. - Maximum bend radius of flexible optical fiber light pipe is 10X the outer diameter. - Available in 1mm, 2mm optical fiber diameter. - Optical fiber length: 1.0 in. to over 100 ft. - Allowable cut length is up to 3 decimal places. - Optical fiber colors: red, green, blue, yellow, white, black. - Wide range of lens sizes, lens profiles, and lengths. |
| ORFLP (330) | Board mount adapter system with built-in Bivar 4-pin Through-Hole Superflux LED and Flexible Light Pipe. - Available in 1mm, 2mm optical fiber diameter. - Optical fiber length: 1.0 in. to over 100 ft. - Single and multi-color Superflux LEDs. - Lens shapes: Round, Oval, Rectangular - Range of lens sizes, and colors available. - Optical fiber colors: red, green, blue, yellow, white, black. |
| FLP (594) | Board mount adapter with built-in Bivar Through-Hole LED and Flexible Light Pipe. - Available in 1mm, 2mm optical fiber diameter. - Optical fiber length: 1.0 in. to over 100 ft. - Vertical and right-angle adapter configurations. - Single and multi-color Through-Hole LEDs - Range of lens sizes, shapes, and colors. - Optical fiber colors: red, green, blue, yellow, white, black. |
| SMTV01 (20) | Surface mount adapter system with built-in 0606 SMD LED. - Single and multi-color SMD LED. - Ordered separately with Bivar 2mm Optical Fiber/Lens Cap. - Wide range of lens sizes, lens profiles, and lengths. - Adapter provided on tape and reel for easy installation. - Optical fiber colors: red, green, blue, yellow, white, black. |
Surface Area Light Guides
When your user interface design requires visual indicators in real time, Bivar has solutions perfect for applications where a discreet yet effective backlighting or side-lighting is a critical element. Don’t let the good looks throw you, our surface area light guides are just as effective as they are attractive.
Light Guides
When your user interface design requires visual indicators in real time, Bivar has solutions perfect for applications where a discreet yet effective backlighting or side-lighting is a critical element. Don’t let the good looks throw you, our surface area light guides are just as effective as they are attractive.
| SAC (16) | Circular shaped surface area light guides feature a high quality RGB light engine and are available in two sizes. SAC provides easy product installation with several mounting options including mounting screw and adhesive attachment. |
| SAR (16) | Rectangular shaped surface area light guides feature a high quality RGB light engine and are available in two sizes. SAR provides easy product installation with several mounting options including snap, slide-in, mounting screw, and adhesive attachment. |
| SASG (12) | Surface Area Side Glow Light Guides are designed for seamless integration near essential sensors and controls. They are ideal for applications that demand discreet yet effective LED edge side-lighting. Critical system status information can be relayed visually in real time, making these guides a crucial element for user interface design. |
LED Emitters
PLCC
Versatile single color and RGB PLCC LEDs are light pipe compatible for use in all types of rugged environment applications.
| SMTL3020 (5) | Industry standard miniature SMTL3020 PLCC package. - Ideal for harsh working environments - Use with Bivar Press Fit or Board Mounted Light Pipes. - Available in a variety of colors with high luminous intensity. - Strong thermal performance and long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTL3528 (4) | Industry standard miniature SMTL3528 PLCC package. - Ideal for harsh working environments - Use with Bivar Press Fit or Board Mounted Light Pipes. - Available in a variety of colors with high luminous intensity. - Strong thermal performance and long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTLA5018 (1) | Industry standard RGB(W) addressable SMTLA5018 PLCC package. - Ideal for harsh working environments - Use with Bivar Press Fit or Board Mounted Light Pipes. - Integrated IC for full-color control - Strong thermal performance and long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTLA5050 (2) | Industry standard RGB(W) addressable SMTLA5050 PLCC package. - Ideal for harsh working environments - Use with Bivar Press Fit or Board Mounted Light Pipes. - Integrated IC for full-color control - Strong thermal performance and long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTL2 (19) | PLCC2 SMD LED Side View Low Profile Package. - Reinforced package for use with Bivar Light Pipes in harsh environment applications. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTL4 (14) | PLCC4 SMD LED Top View Low Profile Package. - 2 chips in one low profile package. - Reinforced package for use with Bivar Light Pipes in harsh environment applications. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMTL6 (7) | PLCC6 SMD LED Top View Low Profile Package. - Flexible 3 chip design, Chips can be driven individually or in combinations. - Reinforced package for use with Bivar Light Pipes in harsh environment applications. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SMS1105 (9) | PLCC2 SMD LED Side View Low Profile Package. - Reinforced package for use with Bivar Light Pipes in harsh environment applications. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
Surface Mount Miniature
Industry standard high quality SMD LEDs for individual use or with Bivar Light Pipes.
| SM0402 (7) | Ultra-miniature 0402 industry standard SMD LED package. - Ideal for status indication, display backlighting. - Use with Bivar Panel Press-Fit Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM0603 (16) | Miniature 0603 industry standard SMD LED package. - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM0605 (4) | Miniature 0605 industry standard SMD LED package. - Bivar’s smallest bi-color SMD LED. 2 chips in one small package and footprint. - Ideal for small board designs that require multiple color outputs. - Use with Bivar Rigid Light Pipes. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM0805 (16) | Miniature 0805 industry standard SMD LED package - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM0807 (4) | Miniature 0807 industry standard SMD LED package - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM1204 (16) | Miniature 1204 industry standard right angle mounting SMD LED package. - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
| SM1206 (28) | Miniature 1206 industry standard SMD LED package. - Narrow 30° inner lens viewing angle. - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Available in a wide variety of color and luminous intensities. - Low power, long life reliability. - Supplied in tape and reel. |
| SM1210 (6) | Miniature 1210 industry standard SMD LED package. - Two chips in one package for multiple color outputs. - Ideal for general indication, display backlighting. - Use with Bivar Rigid Light Pipes. - Low power, long life reliability. - AvailableWide viewing angle 120°. - Supplied in tape and reel. |
Through Hole
Industry standard high quality Through-Hole LEDs for individual use or with Bivar Light Pipes.
| 1.8MM (11) | Industry standard 1.8mm small footprint package. - Available with shouldered lead frames. - Built-in strain relief ideal for right angle holder assemblies requiring lead bends. - Recommended for Bivar H-3 and H-4 holder assemblies. - Ideal for general indication, display backlighting. |
| 3MM (T-1) (56) | Industry standard 3mm (T-1) package. - Two lead or 3 lead configurations. - Available with flanged and shouldered lead frames. - Flanged leads ideal for panel lens clip and ring assemblies. - Shouldered leads ideal for vertical spacer assemblies without lead bends. - Built-in strain relief ideal for right angle holder assemblies requiring lead bends. - Ideal for general indication, display backlighting. |
| 5MM (T-1 3/4) (36) | Industry standard 5mm (T-1) package. - Two lead or 3 lead configurations. Round and rectangular lens shapes. - Available with flanged and shouldered lead frames. - Flanged leads ideal for panel lens clip and ring assemblies. - Shouldered leads ideal for vertical spacer assemblies without lead bends. - Built-in strain relief ideal for right angle holder assemblies requiring lead bends. - Ideal for general indication, display backlighting. |
| Rectangular (28) | Industry standard rectangular package. - Available in industry standard lead frame styles. - Lead frames used in vertical assemblies and right angle holder assemblies. - Recommended for H-480C holder assemblies. - Ideal for status indication, bar graph displays. |
UV/IR
Industry standard high quality SMD and Through-Hole UV-A LEDs.
| SMTL3528UV (1) | 3.10mm x 2.80mm SMTL3528 SMD LED Top View Package, UV. |
| UV3TZ (10) | 3mm (T-1) industry standard tight tolerance Through-Hole LED UV package. - UV-A wavelengths from 385nm to 405nm. - Tight tolerance to +/- 2.5nm. - Built-in Zener diode provides protective circuit against electrostatic discharge (ESD). - Water clear lens and narrow viewing angles. - Ideal for curing, medical applications, air purification, dermatological equipment. - High efficiency, low power consumption, low current requirement. |
| UV5TZ (10) | 5mm (T-1 3/4) industry standard tight tolerance Through-Hole LED UV package. - UV-A wavelengths from 385nm to 405nm. - Tight tolerance to +/- 2.5nm. - Built-in Zener diode provides protective circuit against electrostatic discharge (ESD). - Water clear lens and narrow viewing angles. - Ideal for curing, medical applications, air purification, dermatological equipment. - High efficiency, low power consumption, low current requirement. |
| SMTL3528IR (1) | Industry standard miniature SMTL3528 PLCC IR package. - Wavelength 940nm. - 27.5mW/sr radiant intensity - Long life and reliability. - Supplied in tape and reel. |
Panel and Circuit Board Indicators
Circuit Board Right Angle
Circuit board mount indicators with right angle interlocking holders for design flexibility.
| H100 (177) | Single-level high one to four station right angle circuit board indicator. - 3mm (T-1) LED with single and multi-colors. - Interlocking holders make these highly configurable from one to four station. - Shock and vibration resistant, ideal space saving solution. - Variety of lens and color combinations. |
| H200 (160) | Two-level high one to four station right angle circuit board indicator. - 3mm (T-1) LED with single and multi-colors. - Interlocking holders make these highly configurable from one to four positions. - Shock and vibration resistant, ideal space saving solution. - Variety of lens and color combinations. |
| H300 (136) | Three-level high right angle circuit board indicator. - 3mm (T-1) LED with single and multi-colors. - Range of centerline options for optimum indication alignment. - Shock and vibration resistant, ideal space saving solution. - Variety of lens and color combinations. |
| H400 (154) | Four-level high one to four station right angle circuit board indicator. - 3mm (T-1) LED with single and multi-colors. - Interlocking holders make these highly configurable from one to four positions. - Shock and vibration resistant, ideal space saving solution. - Variety of lens and color combinations. |
| H900 (8) | One to four level high one station right angle circuit board indicator. - 2mm x 7mm Rectangular Through Hole LED with single and multi-colors. - Horizontal LED positioning within holder. - Shock and vibration resistant, ideal space saving solution. - Variety of lens and color combinations. |
Circuit Board Vertical
Circuit board mount indicators with vertical interlocking holders for design flexibility.
| ELM (886) | Extruded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 ¾) LED. - Range of height options to precisely elevate LEDs vertically from PCB. - Customizable lengths. - Also provided with an LED as a complete assembly. |
| ERM (3) | Extruded self-retaining rectangular Through Hole LED mount. - Use with Bivar 3mm (T-1) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB. - Customizable lengths. |
| LTM (47) | Molded self-retaining LED mount assembled with bi-color Through-Hole LED. - 5mm (T-1 3/4) flanged LED with bi-color options. - Range of height options to precisely elevate LEDs vertically from PCB. - Variety of lens sizes, lens profiles, and lens appearances. - Customizable lengths. |
| RL (3) | Molded self-retaining rectangular LED mount assembled with single and multi-color Through-Hole LED. - 2mm rectangular LED with single and multi-color options. - Range of height options to precisely elevate LEDs vertically from PCB. - Post design facilitates cleaning and inspection. - Customizable lengths. |
| SLM (114) | Molded self-retaining LED mount assembled with bi-color Through-Hole LED. - 3mm (T-1) flanged LED with bi-color options. - Range of height options to precisely elevate LEDs vertically from PCB. - Variety of lens sizes, lens profiles, and lens appearances. - Customizable lengths. |
Panel Mount Metal
Industrial-grade indicators with a wide range of options for general applications.
| MPC (160) | Metal panel mount indicator with high visibility domed lens. - Available in 3mm (T-1) or 5mm (T-1 ¾) flanged LED lens size. - Voltage input options of 5V and 12V. - Wire terminals or with 24AWG stripped and tinned wire leads. - Mounting hardware included, packed separately. - Range of single and multi-colors, narrow viewing angle lens appearance options. |
| MPR (103) | Metal panel mount indicator with high visibility domed lens. - Available in 3mm (T-1) or 5mm (T-1 ¾) flanged LED lens size. - Voltage input options of 5V and 12V. - Wire terminals or with 24AWG stripped and tinned wire leads. - Mounting hardware included, packed separately. - Range of single and multi-colors, narrow viewing angle lens appearance options. |
Panel Mount Metal IP Rated
Industrial-grade indicators with a wide range of options for rugged applications.
Panel Mount Plastic
Reliable indicators with a wide range of options for general applications.
| PM3/PM5 (33) | Plastic panel mount indicator with high visibility LED domed lens. - Available in 3mm (T-1) or 5mm (T-1 ¾) LED lens size. - Voltage input options of 5V and 12V. - Wire terminals or with 24AWG stripped and tinned wire leads. - Mounting hardware included, packed separately. - Range of single and multi-colors, narrow viewing angle lens appearance options. |
| PM53 (20) | Plastic panel mount indicator with 3-leads high visibility LED domed lens. - Available in 3mm (T-1) or 5mm (T-1 ¾) LED lens size. - Voltage input 2.8V. - Wire terminals. - Bi-color, narrow viewing angle diffused lens appearance. |
| PMR4 (2) | Plastic panel mount indicator with high visibility rectangular LED lens. - Available in 2mm x 4mm LED lens size. - Voltage input 2.6V to 4.5V. - Wire terminals or with 24AWG stripped and tinned wire leads. - Single color, wide viewing angle diffused lens appearance. |
Panel Mount Plastic IP Rated
Reliable indicators with a wide range of options for rugged applications.
LED Mounts
Panel Mounting Clip
Firmly mount and secure Through-Hole LEDs.
| CR (14) | Firmly mount and secure Through-Hole LEDs. - Use with Bivar 3mm (T-1) or 5mm (T-1 3/4) flanged LED. - Securely and uniformly position and reinforce the LED. - Provide added protection from shock and vibration. |
Right Angle
Right angle interlocking holders for design flexibility.
| 900 (7) | Molded right angle interlocking Through Hole LED Mount. - Use with Bivar 3mm (T-1) and 5mm (T-1 ¾) Through Hole LED. - Interlocking feature provides flexibility for coupling in arrays. - Available in a range of heights and centerlines. For 2 or 3 leaded LEDs. |
| H (82) | Multi-level high one to four station right angle LED holder. - Use with Bivar 3mm (T-1) LED. - Interlocking holders make these highly configurable from one to four station. - Shock and vibration resistant, ideal space saving solution. - Variety of heights, centerlines, lens, and color combinations. - Also available as complete Circuit Board Indicator assembly. |
Vertical
Vertical interlocking holders for design flexibility.
| 400 (131) | Molded vertical Through Hole LED Mount. - Use with Bivar 3mm (T-1) and 5mm (T-1 ¾) Through Hole LED. - Vertically elevates Through Hole LEDs from the PCB. - Funnel shaped lead entry holes for ease of assembly. - Post design facilitates cleaning and inspection. - Available in a range of heights. From .120 in. (3.0mm) to 1.080 in. (27.4mm) |
| ELM (1642) | Extruded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 ¾) LED - Range of height options to precisely elevate LEDs vertically from PCB - Customizable lengths - Also provided with an LED as a complete assembly |
| ERM (273) | Extruded self-retaining LED mount assembled with bi-color Through-Hole LED. - 3mm (T-1) flanged LED with bi-colors options. - Range of height options to precisely elevate LEDs vertically from PCB. - Variety of lens sizes, lens profiles, and lens appearances. - Customizable lengths. |
| LTM (54) | Molded self-retaining Through Hole LED mount. - Use with Bivar 5mm (T-1 3/4) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB in severe temperature environments. - Customizable lengths. |
| MLM (75) | Molded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 3/4) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB in severe temperature environments. - Customizable lengths. |
| MRM (37) | Molded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 3/4) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB. - Customizable lengths. |
| NTM (56) | Molded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 3/4) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB. - Customizable lengths. |
| RL (54) | Molded self-retaining rectangular LED mount. - Use with Bivar 2mm rectangular Through-Hole LEDs. - Range of dimensional options to precisely elevate LEDs vertically from PCB. |
| SLM (54) | Molded self-retaining Through Hole LED mount. - Use with Bivar 3mm (T-1) or 5mm (T-1 3/4) flanged LED. - Range of height options to precisely elevate LEDs vertically from PCB. - Customizable lengths. |
Circuit Board Hardware
Handles
Tight fit? Not a concern. Bivar offers space-saving designs that improve the functionality and offer sturdy access for use in industrial enclosures, panels and subracks. Enclosure handles come in a variety of sizes and finishes.
| Sub Rack Handles (2) | Low profile 2U, 3U, 4U, 6U sub rack handles for optimal strength and leveraging support. - Improves installation and handling with sub rack system. - Mounting hardware included, shipped unassembled. - Range of materials, shapes, and lengths. |
PCB Card Guides
Got a bit of a challenge? Nope, not when you’ve got Bivar. We offer vertical or horizontal circuit board card guides for everything from basic to the most challenging applications and environments. PCB mounting options include everything from low profile to static sensitive and increased retention for those high vibration installations.
| Deep Channel (44) | Supports high temperature, shock, and vibration environments. - Press-fit installation for panel retention. - Multiple slot widths to accommodate wide range of panel thicknesses. - Conductive insert option. - Range of dimensional options. |
| Double-Sided Horizontal (18) | Supports parallel mounting for backplane daughter cards. - Provides innovative mounting method for variety of applications. - Press-fit installation for panel retention. - Range of dimensional options. |
| Economy (50) | Supports greater PCB component density. - Enables maximum component placement. - Press-fit installation for panel retention. - Conductive insert option. - Range of dimensional options. |
| Interchangeable Snap-In (63) | Industry standard Snap-in card guides with conductive insert option. |
| Narrow (26) | Thin footprint and narrow widths for high density stacking in sub rack enclosures. - Provides improved cooling for high density PCB applications. - Press-fit installation for panel retention. - Conductive insert option. - Range of dimensional options. |
| Universal (19) | Universal nylon card guide with grounding clip. - Integrated grounding from PCB to chassis with snap-in mounting pylons. - Press-fit installation for panel retention. - Recommended card thickness .062 in. to .079 in. (1.6mm to 2.0mm) - Recommended panel thickness .047 in. to .090 in. (1.2mm to 2.3mm) - Range of dimensional options. |
| Vertical PCB (9) | Enables vertical installation in a range of widths for 1/16 in. PCBs. - Provides design flexibility for tandem mounting of multiple PCBs. - Press-fit installation for panel retention. - Range of dimensional options. |
PCB Ejectors
Think of this as your latest stress relief tip. Card ejectors increase your PCB longevity, improve accessibility in backplanes and enclosures and maximize security. They are also designed to prevent unnecessary stress on the PCB, circuitry and connectors.
| Circuit Board Card Ejector (134) | Molded self-retaining LED mount assembled with bi-color Through-Hole LED. - 3mm (T-1) flanged LED with bi-color options. - Range of height options to precisely elevate LEDs vertically from PCB. - Variety of lens sizes, lens profiles, and lens appearances. - Customizable lengths. |
PCB Inserters / Extractors
Reduce your use of the word, “oops.” Our snap and lock security on our circuit cards are designed for accessibility without giving up protection of your components. PCB Inserters and Extractors come in a variety of widths and lever styles, plus a wide range of colors.
| Card Puller (9) | Optimal leverage solution for the circuit card insertion and extraction process. - Upturned lever 1.55 in. (39.4mm) for PCB width .062 in. (1.6mm) - Roll pins included, packaged separately. - Pre-assembled with roll pins available upon request. - Range of standard and custom colors. |
| Upturned Lever (9) | Optimal leverage solution for the circuit card insertion and extraction process. - Upturned lever 1.937 in. (49.2mm) - Use with 1/16 in. and 3/32 in. card thickness. - Roll pins included, packaged separately. - Pre-assembled with roll pins available upon request. - Range of standard and custom colors. |
| Upturned or Flat Lever (45) | Optimal leverage solution for the circuit card insertion and extraction process. - Upturned or flat lever for PCB width from .062 in. (1.6mm) to .125 in. (3.2mm) - Roll pins included, packaged separately. - Pre-assembled with roll pins available upon request. - Range of standard and custom colors. |
| Upturned with Stop or Straight Lever (5) | Optimal leverage solution for the circuit card insertion and extraction process. - Upturned or straight lever shape. - Use with 1/16 in. card thickness. - Roll pins included, packaged separately. - Pre-assembled with roll pins available upon request. - Range of standard and custom colors. |
Component Hardware
Component Mounts / Insulators
Don’t let your components fall prey to part shamers. Bivar offers a way to mount and protect components with any level of core thickness, from narrow to medium and wide. And while we have a variety of standard lengths, customization is also available.
| Crystal Oscillator Insulators (13) | Optimal crystal oscillator insulation and elevation from the PCB. - Improves performance and cooling efficiency. - Made from UL rated 94VTM-2 polyester film. - Range of dimensional options. |
| Machine-Screw Insulators (10) | High temperature shoulder washer. - Easily insert and spread the. load of threaded fasteners. - Use with component sizes TO-3, TO-66, TO-218, TO-220, TO-247. - Made from UL rated 94V-0 nylon. - Range of dimensional options. |
| Semi-Rigid PVC Mounts (139) | Mount for semiconductors and passive components. - Provides uniform spacing. - Protects components from shock, vibration, and overheating. - Made from UL rated 94V-2 nylon. - Range of dimensional options. |
Component Spacers
Whether you need spacers with staying power or those that can be washed away, Bivar has the Component Spacers to elevate, protect and control production uniformity of delicate leads during assembly or through hole electronic components on PCBs. Not sure we have what you need? Ask us about customization.
| Medium Core (831) | Mount medium width discrete devices at any elevation with thin/thick wall nylon tubular spacers. - Provides accurate positioning at any component elevation. - Inner diameter .090 (2.3) - .105 (2.7) - Outer diameter .125 in. (3.2mm) - .167 in. (4.2mm) - Range of length dimensional options. |
| Narrow Core (1070) | Mount narrow width discrete devices at any elevation with thin/thick wall nylon tubular spacers. - Provides accurate positioning at any component elevation. - Inner diameter .028 (.71) - .032(.81) - Outer diameter .085 in. (2.2mm) - Range of length dimensional options |
| Wash-Away Spacer (237) | Tubular dissolving component spacers. - Provides accurate positioning of through-hole electronic components on PCBs. - Helps control production uniformity. - Dissolve in hot/warm water without trace of residue. - Range of dimensional options. |
| Wide Core (1129) | Mount wide width discrete devices at any elevation with thin/thick wall nylon tubular spacers. - Available in 6mm or 9mm front-mount lens size. - Vertical and right-angle configurations. - Ideal for space-constrained spaces inside enclosures and on PCB’s. - Range of lengths and lens colors. - Use with panel thickness 0.059 in. (1.5mm) to 0.236 in. (6.0mm) - Hardware included. |
PCB Standoffs / Supports
It’s like a bouncer for your circuit boards. Don’t let vibration or electrical transmissions threaten the integrity of your circuit boards and components. Position and protect them with PCB Standoffs/Supports from Bivar. Our design accommodates standard screw sizes in firm-retaining and self-retaining options.
| #2 Screw Nylon Tubular PCB Standoffs (43) | #2 screw standoff solution for stacking printed circuit boards. - Inner diameter .091 in. (2.3mm) - Outer diameter .187 in. (4.7mm) - Range of height options |
| #4 Screw Nylon Tubular PCB Standoffs (85) | Screw standoff solution with outer diameter dimensional options, and firm retention to stack circuit boards. - Inner diameter .125 in. (3.2mm) - Outer diameter .187 in. (4.7mm) - .250 in. (6.4mm) - Range of height options. |
| #6 Screw Nylon Tubular PCB Standoffs (47) | #6 screw standoff solution for stacking printed circuit boards. - Inner diameter .147 in. (3.7mm) - Outer diameter .250 in. (6.4mm) - Range of height options. |
| #8 Screw Nylon Tubular PCB Standoffs (47) | #8 screw standoff solution for stacking printed circuit boards. - Inner diameter .171 in. (4.3mm) - Outer diameter .250 in. (6.4mm) - Range of height options. |
| Self-Retaining PVC Screw Spacers (117) | #4, #6, M3 screw size spacers for reliable PCB stacking and stability. - Ribbed inner-wall design provides a secure fit. - Made from UL rated 94V-o PVC. - Range of height options. |
